ABOUT US

Titus SDR, Inc. is an engineering, manufacturing and distributing company of electronic products.  The rTablet / rTab unit design and prototyping has been carried out by the engineering team located in the U.S.A.

Pricing of the rTablet is dependent upon features. For details and ordering information, please contact: sales@titus-sdr.com

Pricing of the rTab is dependent upon features. For details and ordering information, please contact: sales@titus-sdr.com

USD $150

Plus shipping and handling.  Customs fees of country of destination are the responsibility of the buyer.

USD $120

Plus shipping and handling.  Customs fees of country of destination are the responsibility of the buyer.

Development History

 The design of rTablet / rTab defined radio receiver started in 2014. It soon became evident that electronic products available on the market could not be modified to incorporate the advanced features requested by potential buyers. This initiated the process of the innovative design of the Titus SDR (Software Defined Radio) unit. The engineering team started with a general purpose computer unit and embedding it in a broadband radio receiver module.

All types of applications, including RF software, could be installed. For example, DRM capabilities could be added as DRM is an open source. Dream Linux app was converted to run under Android mobile operating system.

The Titus rTablet / rTab being introduced to the market, is a low cost, high performance platform with many RF and PC factory installed applications.

Key feature of rTablet / rTab is the compatibility with analog (SW, AM, FM) and digital standards (DRM, DRM+, DAB, DAB+, HD). Consequently the market of rTablet / rTab is global.

General Features

Processor:

  • Quad-Core ARM A53 processor @ 1.2
  • Android 5+/6+/Remix
  • 1GB RAM
  • 8GB Flash

Display/Touch Panel:

  • 7″ TFT (1024 x 600)
  • 5 point capactivie touch panel
  • Full color; high brightness

Audio:

  • 5 watt stereo audio
  • High capacity Li-poly battery
  • HDMI
  • Micro-USB OTG Connector
  • WiFi/Bluetooth
  • Optional camera
  • Micro-SD Slot

Miscellaneous:

  • External function buttons
  • Top mounted controls: Volume +/-, Tune, Set
  • Built in microphone
  • Jack for headphones and external microphone
  • Power: +5VDC, World-wide adapaters available

Mechanical:

  • Actual Size: 290 x 150 x 45 mm (11.4 x 5.9 x 1.8″)
  • Molded from rugged ABS plastic
  • Base fold into a protective cover for the screen
  • Cover has slot allowing listening with screen on

RF Features

Built in RF Tuner:

  • High sensitivity
  • Low noise
  • WideBand: (100 KHz to 2 GHz)
  • Balanced tuned ferrite antenna (MW)
  • Built-in Whip
  • Jack for external antenna

Software:

  • Demodulation software for AM, FM, and Digital
  • Open source software Radio libraries
  • WiFi hotspot
  • Filecasting – Share RF broadcasts and files
